LENGTH RANGE: 2000mm to 3000mm

LOADING CAPACITY: 300kg / 600kg

Rotating Version & Easy-Move Version

Van Loading Ramps
Rotating Van Ramps
CODE ROTATINGLOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANRM 2000-6330020001000650102025025
VANRM 2250-6330022501000650120025030
VANRM 2500-6330025001000650130025035
VANRM 2750-6330027501000650148025037
VANRM 3000-6330030001000650157025040
CODE ROTATINGLOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANRM 2000-8330020001150800102025028
VANRM 2250-8330022501150800120025030
VANRM 2500-8330025001150800130025035
VANRM 2750-8330027501150800148025037
VANRM 3000-8330030001150800157025040
Rotating Van Ramps
CODE ROTATINGLOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANRM 2000-8660020001150800102025032
VANRM 2250-8660022501150800120025035
VANRM 2500-8660025001150800130025040
VANRM 2750-8660027501150800148025043
VANRM 3000-8660030001150800157025045
CODE ROTATINGLOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANRM 2000-106600200013501000102025047
VANRM 2250-106600225013501000120025053
VANRM 2500-106600250013501000130025058
VANRM 2750-106600275013501000148025062
VANRM 3000-106600300013501000157025068
Easy-Move Van Ramps
CODE EASY-MOVELOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANSM 2000-6330020001000650102025025
VANSM 2250-6330022501000650120025030
VANSM 2500-6330025001000650130025035
VANSM 2750-6330027501000650148025037
VANSM 3000-6330030001000650157025040
CODE EASY-MOVELOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANSM 2000-8330020001150800102025028
VANSM 2250-8330022501150800120025030
VANSM 2500-8330025001150800130025035
VANSM 2750-8330027501150800148025037
VANSM 3000-8330030001150800157025040
Easy-Move Van Ramps
CODE EASY-MOVELOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANSM 2000-8660020001150800102025032
VANSM 2250-8660022501150800120025035
VANSM 2500-8660025001150800130025040
VANSM 2750-8660027501150800148025043
VANSM 3000-8660030001150800157025045
CODE EASY-MOVELOADING CAPACITY (kg)LENGTH (mm)E OVERALL (mm)W INTERNAL WIDTH (mm)H HEIGHT (mm)P DEPTH (mm)WEIGHT Pair (kg)
VANSM 2000-106600200013501000102025047
VANSM 2250-106600225013501000120025053
VANSM 2500-106600250013501000130025058
VANSM 2750-106600275013501000148025062
VANSM 3000-106600300013501000157025068
