LENGTH RANGE: 1500mm to 3500mm

LOADING CAPACITY: 1685kg to 849kg

* Available with or without Edges

H72 Ramps Spec
Surfaces
CODE WITHOUT EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H72/15S168516851685150025031018
H72/20S160016001600200025031023
H72/25S136015901600250025031028
H72/30S105011801350300025031033
H72/35S8499361036350025031039
CODE WITHOUT EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H72/15SL168516851685150045051024
H72/20SL160016001600200045051030
H72/25SL136015901600250045051036
H72/30SL105011801350300045051043
H72/35SL8499361036350045051050
CODE WITH EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H72/15SB16851685168515002503102418
H72/20SB16001600160020002503102423
H72/25SB13601590160025002503102428
H72/30SB10501180135030002503102433
H72/35SB849936103635002503102439
CODE WITH EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H72/15SBL16851685168515004505102424
H72/20SBL16001600160020004505102430
H72/25SBL13601590160025004505102436
H72/30SBL10501180135030004505102443
H72/35SBL849936103635004505102450
