H60 Aluminum Ramps
The H60 ramps have a loading capacity that reaches 2000 kg. This product can be used also in earthmoving, or with trailers. This series too offers a foldable option, for small storage necessities
LENGTH RANGE: 1500mm to 3500mm
LOADING CAPACITY: 1750kg to 750kg
* Available with Edges
| CODE FOLDABLE | LOADING CAPACITY PAIR IN KG / WHEELBASE 750 mm | LOADING CAPACITY PAIR IN KG / WHEELBASE 1000 mm | LOADING CAPACITY PAIR IN KG / WHEELBASE 1250 mm | LENGTH (mm) | WIDTH (mm) | WEIGHT Pair (kg) |
|---|---|---|---|---|---|---|
| H60/15SP | 1220 | 1220 | 1220 | 1500 | 300 | 23 |
| H60/20SP | 1090 | 1090 | 1090 | 2000 | 300 | 30 |
| H60/25SP | 1000 | 1000 | 1000 | 2500 | 300 | 37 |
| H60/30SP | 950 | 950 | 950 | 3000 | 300 | 44 |
| H60/35SP | 750 | 750 | 750 | 3500 | 300 | 51 |
| CODE | LOADING CAPACITY PAIR IN KG / WHEELBASE 750 mm | LOADING CAPACITY PAIR IN KG / WHEELBASE 1000 mm | LOADING CAPACITY PAIR IN KG / WHEELBASE 1250 mm | LENGTH (mm) | WIDTH (mm) | WEIGHT Pair (kg) |
|---|---|---|---|---|---|---|
| H60/15S | 1750 | 1750 | 1750 | 1500 | 300 | 20 |
| H60/20S | 1700 | 1700 | 1700 | 2000 | 300 | 27 |
| H60/25S | 1650 | 1700 | 1700 | 2500 | 300 | 34 |
| H60/30S | 1250 | 1405 | 1610 | 3000 | 300 | 41 |
| H60/35S | 990 | 1090 | 1215 | 3500 | 300 | 48 |
