LENGTH RANGE: 2500mm to 5000mm

LOADING CAPACITY: 12800kg to 8175kg

* Available with or without Edges

H220 Ramps Specification
CODE WITHOUT EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H220/25S1280012800128002500500620114
H220/30S1200012000120003000500620134
H220/35S1200012000120003500500620154
H220/40S1200012000120004000500620173
H220/45S960012000120004500500620194
H220/50S8175880095355000500620216
CODE WITH EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H220/25B128001280012800250050058050108
H220/20B120001250012500300050058050128
H220/35B122001220012200350050058050146
H220/40B120001200012000400050058050167
H220/45B96001200012000450050058050188
H220/50B817588009535500050058050210
CODE WITH EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H220/25BL128001280012800250055062550114
H220/30BL120001250012500300055062550134
H220/35BL122001220012200350055062550154
H220/40BL120001200012000400055062550173
H220/45BL96001200012000450055062550194
H220/50BL817588009535500055062550216
