LENGTH RANGE: 1500mm to 5000mm

LOADING CAPACITY: 11200kg to 5450kg

* Available with or without Edges

H190 Ramps Specification
CODE WITHOUT EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H190/15S112001120011200150050061068
H190/20S108001100011000200050061085
H190/25S1040010800108002500500610104
H190/35S1020010500105003000500610122
H190/35S970010450104503500500610140
H190/40S7700858096504000500610163
H190/45S6400698076804500500610180
H190/50S5450587063605000500610200
CODE WITH EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H190/15B11200112001120015005005954368
H190/20B10800110001100020005005954385
H190/25B104001080010800250050059543104
H190/30B102001050010500300050059543122
H190/35B97001045010450350050059543140
H190/40B770085809650400050059543160
H190/45B640069807680450050059543174
H190/50B545058706360500050059543196
