LENGTH RANGE: 1500mm to 4500mm

LOADING CAPACITY: 7200kg to 3365kg

* Available with or without Edges

H135 Ramps Specification
CODE WITHOUT EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H135/15S720072007200150034042048
H135/20S720072007200200034042060
H135/25S720072007200250034042070
H135/30S685572007200300034042085
H135/35S512058506825350034042092
H135/40S4065452050854000340420104
H135/45S3365367040354500340420117
CODE WITHOUT EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H135/15SL720072007200150039047054
H135/20SL720072007200200039047066
H135/25SL720072007200250039047076
H135/30SL685572007200300039047089
H135/35SL512058506825350039047096
H135/40SL4065452050854000390470110
H135/45SL3365367040354500390470123
CODE WITH EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H135/15B72007200720015003504052548
H135/20B72007200720020003504052560
H135/25B72007200720025003504052570
H135/30B68557200720030003504052585
H135/35B51205850682535003504052592
H135/40B406545205085400035040525104
H135/45B336536704035450035040525117
CODE WITH EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1750 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
2000 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H135/15BL72007200720015004004552550
H135/20BL7200720072002004004552562
H135/25BL72007200720025004004552576
H135/30BL68557200720030004004552589
H135/35BL51205850682535004004552596
H135/40BL406545205085400040045525110
H135/45BL336536704035450040045525123
