LENGTH RANGE: 2000mm to 4000mm

LOADING CAPACITY: 4110kg to 2600kg

* Available with or without Edges

H125 Ramps Specification
surfaces
CODE WITHOUT EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H125/20S411041104110200032040043
H125/25S411041104110250032040050
H125/30S390039003900300032040061
H125/32S360039003900320032040065
H125/35S320035003900350032040069
H125/40S260028003100400032040080
CODE WITHOUT EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)WEIGHT Pair (kg)
H125/20SL411041104110200035043045
H125/25SL411041104110250035043051
H125/30SL390039003900300035043062
H125/32SL360039003900320035043066
H125/35SL320035003900350035043071
H125/40SL260028003100400035043081
CODE WITH EDGESLOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H125/20B41104110411020003203853544
H125/25B41104110411025003203853550
H125/30B39003900390030003203853560
H125/32B36003900390032003203853564
H125/35B32003500390035003203853569
H125/40B26002800310040003203853579
CODE WITH EDGES WIDERLOADING CAPACITY PAIR IN KG / WHEELBASE
1000 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1250 mm
LOADING CAPACITY PAIR IN KG / WHEELBASE
1500 mm
LENGTH (mm)INTERNAL WIDTH (mm)EXTERNAL WIDTH (mm)EDGES HEIGHT (mm)WEIGHT Pair (kg)
H125/20BL41104110411020003504153546
H125/25BL41104110411025003504153552
H125/30BL39003900390030003504153561
H125/32BL36003900390032003504153565
H125/35BL32003500390035003504153571
H125/40BL26002800310040003504153580
